P12-21A Følsom og holdbar knapkontakt

Sikkerhedscertificering Tekniske data: Dette produkt er certificeret af UL, TUV, VDE og CQC.

UL-certificerings tekniske parametre:
12 (10) A 125/250 VAC T125 5E4
12 A 125/250 VAC T125 5E4


VDE-certificerings tekniske parametre:
10 (8) A 250 VAC T120/55 10E3


Tekniske parametre for TUV-certificering:
12 (10) A 250 VAC T125 1E4

10 A 24/36 VDC T125 1E4


Tekniske parametre for CQC-certificering:
12 (10) A 250VAC T125 1E4

Produktinformation

Konstrueret til præcision og bygget til at holde ud, den følsomme og holdbare knapkontakt er benchmark inden for alsidig switch-teknologi. Denne højtydende komponent er designet med en intelligent intern arkitektur og leverer problemfri taktil feedback og langsigtet pålidelighed, hvilket gør den til et uundværligt element i både husholdnings- og industriapplikationer.

Kernen i dens appel er en omhyggeligt raffineret kontaktmekanisme, der sikrer øjeblikkelig respons og urokkelig konsistens ved hvert tryk. Uanset om det er at aktivere en ledningsfri støvsuger, tænde en genopladelig lampe eller styre et kompakt hængende strygejern, reagerer denne kontakt med tavs sikkerhed og skarp præcision. Det er ikke bare en knap - det er et kommandocenter i miniatureform.

Indkapslet i et robust, men slankt hus, modstår kontakten slid, fugt og miljøbelastninger, hvilket gør den lige så velegnet til udendørs haveredskaber som elektriske plæneklippere eller hækkeklippere. Dens universelle kompatibilitet forenkler integration på tværs af et bredt spektrum af elektriske enheder, mens dens intuitive aktivering kræver minimal indsats, hvilket forbedrer brugervenligheden for alle aldersgrupper.

Fra moderne hjem til professionelle værksteder løfter den følsomme og holdbare knapkontakt brugeroplevelsen gennem intelligent design og kompromisløst håndværk. Testet ud over industristandarder, tåler den titusindvis af aktivering uden forringelse af ydeevnen – hvilket garanterer driftsintegritet under de mest krævende forhold.

Vælg kontakten, der blander subtil følsomhed med urokkelig holdbarhed. Vælg selvtillid. Vælg kontrol.

Om SHQIJIA

Shanghai Qijia Electronics Co., Ltd. was founded in 2004. After more than two decades of development and accumulation, it has grown into a high-tech enterprise integrating the design, R&D, manufacturing, sales, and service of high-quality appliance switches, establishing a professional and reliable brand image in the industry.



The company's core product line, "shqijia," covers a wide range of AC and DC appliance switches, including micro switches, rocker switches, pushbutton switches, trigger switches, and rotary switches, as well as AC and DC circuit board modules and controllers. These products are widely used in AC and DC power tools, electric garden tools, cleaning equipment, household appliances, medical equipment (oxygen concentrators), generators, electric strollers, water pumps, and other electronic and mechanical fields, providing customers in various industries with highly adaptable core component solutions.



I 2025 åbnede virksomheden en ny fabrik, som tilbyder et behageligt miljø og bekvem transport. With over 150 employees, over 20 assembly lines, more than 20 injection molding machines, and over 40 automated equipment, the company boasts an annual production capacity exceeding 80 million units and annual sales exceeding 100 million yuan, providing stable and efficient product supply support to customers worldwide.



To ensure product quality and international compliance, the company has established a state-of-the-art switch testing center (laboratory) that is accredited by the US UL WTDP Witnessed Laboratory and fully ISO 9001 Quality Management System. Its entire product line has successfully passed multiple international certifications, including UL and ETL in the US, TÜV, CE, SEMKO, and CB in Europe, KC in South Korea, and CQC in China, fully meeting the access requirements of diverse global markets.



In addition, the company possesses professional independent product and mold design capabilities, providing customized development services based on individual customer needs and precisely matching diverse application scenarios. In production, the company not only incorporates advanced manufacturing technologies and product processes, but also has a FFU cleanroom to ensure precise process implementation. In recent years, the company has implemented larger-scale automation, significantly improving production efficiency and product quality consistency, laying a solid foundation for the continuous delivery of high-quality products.



Adhering to the core principle of "Quality is the lifeblood of the enterprise, and wholehearted customer service," the company is committed to building a globally renowned high-end brand of appliance switches. I øjeblikket optimerer vi løbende vores R&D-kapaciteter og produktionsstandarder for præcist at imødekomme internationale markedskrav. Vi uddyber også samarbejdet med globale partnere for at levere værdifulde løsninger til forskellige applikationsscenarier. Going forward, Qijia will further expand its global presence, upholding the principles of integrity and innovation, and striving to build long-term, mutually beneficial partnerships with customers worldwide.
